One Clik Button Embossedkeypad Switch Panel With Flexible Copper Cable

Considerations

• Integration: Must be compatible with other systems, potentially using protocols like RS-232, I2C, or wireless communication.
• User Interface Design: The layout should be intuitive, ensuring users can easily understand and use the panel.
• Durability: Especially important in industrial settings; panels may need to be waterproof or resistant to dust.

Example Features

• Backlighting: For visibility in low-light conditions.
• Feedback Mechanism: Such as beeps or vibrations to confirm input.
• Customizable Layout: Users can program specific functions to different buttons.

Components

• Microcontroller: The brain of the panel that processes inputs from the keys and sends commands to other devices.
• Power Source: Can be powered by batteries or connected to a mains supply, depending on the application.
• Buttons/Keys: These can be tactile, membrane, or capacitive touch types, allowing users to input commands.
• LED Indicators: Often used to provide visual feedback on the status of the device or system (e.g., power on/off).

Applications

• Access Control: Used in security systems for entering codes to unlock doors or systems.
• Home Automation: Controls lights, thermostats, and security systems.
• Industrial Controls: Operates machinery or processes in manufacturing environments.

Product Descriptions :

Common membrane keypad structure choose :







Other photo show :


Product Index:

Operating voltage: 35V DC

Operating current: 100mA 1W

Contact resistance: < 100 Ohms

Open circuit resistance: ≥ 10MΩ at 100V

Operating temperature: Flat/Metal dome:-20°c to +80°c

Storage temperature: Flat/Metal dome:-40°cto +80°c

Life expectancy Flat type≥5,000,000 times Tactile type≥1,000,000 times

Switch stroke: 0.1 to 0.6mm

Contact bounce: 5 to 30ms

Actuation force tolerance: +/- 20 to 45g

Tactile ratio: FC > 40%

Operating humidity: up to 95% RH









Our Services :
1 Reply your inquiry within 24 working hours

2 Customize design is available ,OEM and ODM are welcome

3 Experienced Staffs answer your all question in professional and fluent English

4 Exclusive and unique solution can be provided to our customers by our well-trained and professional engineers and staffs

5 Good service ,High quality ,test all goods and short lead time supply

6 we can make any shape ,size ,color ,technology such like button ,LED mounted ,sensor mounted ,and so on based on your request

7 Before mass goods ,we will supply the sample for your approved ,before proofing ,we will design the artwork for your confirm first ,both of them are in order to reduce the cost in the mass goods for you

Taida is a factory and was founded in the 2010 year in China, which focus on the professional design and manufacture of Membrane Switch and Graphic overlays (including different many kinds membrane switch and graphic overlay ,such like LED ,FPC circuit ,waterproof and tactile ,PMMA ,protective film and so on )manufacturers,

Experience:

Taida and engineers have Highly over 15 years experienced on Membrane switch and graphic overlay designs, 500+ customers from worldwide such like USA,UK ,Germany and others , 1000+ new designs per year

Factory Strength and Production Capacity:

Over 2000 square meters of modern plant, spacious and bright clean workshop; more than 25 full Automatic and Semi-Automatic printing machine and other professional Automation equipment,such like testing machine ,UV machine and so on , Taida’ capability has reached 300, 000PCS/month in a very short period since company established.

Quality Control and Ensure :

Taida has got certification of ISO9001: 2000, and also the accreditation for RoHS ,REACH ,UL SGS to meet customer′s requirements.All workers are fully trained before going to production line.and Ensure 100% testing and inspecting before shipping .

Speed & Efficiency:

Concept to Design: < 3 business days

Goods lead time : 12-15 days

Rapid Prototyping: 4-7 days

Overseas Manufacturing

Utilized for larger production volumes and to ensure we can offer the most competitive pricing and Fast lead time to our customers
