Glossy Polyseter Solid Printing Arduino Membrane Keypad For Ventilation Fan Control

Components Needed

1. Arduino Board: Any model (e.g., Arduino Uno, Nano).
2. Membrane Keypad: Typically 4x4 or 4x3 configurations.
3. Connecting Wires: For connecting the keypad to the Arduino.
4. Breadboard (optional): For easier connections.

Wiring the Keypad

1. Identify the Pins: A standard 4x4 keypad has 8 pins.
2. Connections: Connect the keypad pins to the Arduino. For a 4x4 keypad:
   • Row pins (usually 1-4) to any digital pins (e.g., 2-5).
   • Column pins (usually 5-8) to other digital pins (e.g., 6-9).

Explanation of the Code

• Library Inclusion: The Keypad library simplifies the reading of keys.
• Keypad Definition: Define the layout and pins used.
• Setup: Initializes serial communication for debugging.
• Loop: Continuously checks for key presses and prints the pressed key.

Additional Tips

• Debouncing: The library handles key debouncing, but if you notice issues, consider adding a debounce delay.
• Customization: You can change the key layout and the number of rows/columns based on your keypad.
• Libraries: Make sure to install the Keypad library via the Arduino Library Manager.

Product Descriptions :

Common membrane keypad structure choose :






Electrical Properties:
1, operating voltage: ≤ 50VDC
2, working current: ≤ 100mA
3 Contact resistance: 0.5 ~ 5Ω
4 Insulation resistance: ≥ 100MΩ (100VDC)
5, substrate voltage: 2kDVC
6, spring time: ≤ 6ms
7, loop resistance: 60Ω
8, insulation ink voltage: 100VDC


Our Services :
1 Reply your inquiry within 24 working hours

2 Customize design is available ,OEM and ODM are welcome

3 Experienced Staffs answer your all question in professional and fluent English

4 Exclusive and unique solution can be provided to our customers by our well-trained and professional engineers and staffs

5 Good service ,High quality ,test all goods and short lead time supply

6 we can make any shape ,size ,color ,technology such like button ,LED mounted ,sensor mounted ,and so on based on your request

7 Before mass goods ,we will supply the sample for your approved ,before proofing ,we will design the artwork for your confirm first ,both of them are in order to reduce the cost in the mass goods for you



Other photo show :
