Customizable Backlight Tactile Membrane Keypad Embeded With Tact Dome

Advantages

• Cost-Effective: Generally cheaper to manufacture than mechanical keypads.
• Easy to Clean: The flat surface makes it easy to wipe down and maintain hygiene.
• Sealed Design: Protects against environmental factors, prolonging the lifespan of the device.

Applications

• Medical Devices: Utilized in medical equipment that requires user input, such as monitoring devices.
• Automotive Interfaces: Employed in car dashboards and infotainment systems for user controls.
• Consumer Electronics: Used in remote controls, microwaves, and other household appliances.
• Industrial Equipment: Found in machinery and control panels due to their durability and ease of cleaning.

Considerations

• Limited Travel Distance: Some users may prefer the deeper key travel found in mechanical keypads.
• Potential for Wear: Over time, the printed graphics or tactile feedback may degrade.

Features

• Membrane Structure: Composed of multiple layers, including a flexible top layer with printed graphics, a spacer layer, and a bottom layer with conductive traces.
• Durability: Resistant to dust, moisture, and spills, making it suitable for various environments.
• Customization: Can be easily customized in terms of shape, size, and layout, allowing for unique designs.
• Tactile Feedback: Provides a physical response (a slight click or bump) when pressed, enhancing user experience.
• Low Profile: Typically slim and lightweight, which is advantageous for portable devices.

Product Descriptions :

Product Index:

Operating voltage: 35V DC

Operating current: 100mA 1W

Contact resistance: < 100 Ohms

Open circuit resistance: ≥ 10MΩ at 100V

Operating temperature: Flat/Metal dome:-20°c to +80°c

Storage temperature: Flat/Metal dome:-40°cto +80°c

Life expectancy Flat type≥5,000,000 times Tactile type≥1,000,000 times

Switch stroke: 0.1 to 0.6mm

Contact bounce: 5 to 30ms

Actuation force tolerance: +/- 20 to 45g

Common membrane keypad Application :

Other photo show :

How to order

• Send us the drawing ,spec or photo about your product or fill our quotation information table . Get Latest Quote

• Confirm order details and approved our artwork before sample ,confirm our sample before mass goods and Order PI will be sent

• we will send our artwork for your confirm within 3 days before sample making ,and sample lead time is 4-5 business days As usual .

mass goods :as common ,it is 7-10 business days ,which is based on our produce department schedule and product craft and order quantity

Taida is a factory and was founded in the 2010 year in China, which focus on the professional design and manufacture of Membrane Switch and Graphic overlays (including different many kinds membrane switch and graphic overlay ,such like LED ,FPC circuit ,waterproof and tactile ,PMMA ,protective film and so on )manufacturers,

Experience:

Taida and engineers have Highly over 15 years experienced on Membrane switch and graphic overlay designs, 500+ customers from worldwide such like USA,UK ,Germany and others , 1000+ new designs per year

Factory Strength and Production Capacity:

Over 2000 square meters of modern plant, spacious and bright clean workshop; more than 25 full Automatic and Semi-Automatic printing machine and other professional Automation equipment,such like testing machine ,UV machine and so on , Taida’ capability has reached 300, 000PCS/month in a very short period since company established.

Quality Control and Ensure :

Taida has got certification of ISO9001: 2000, and also the accreditation for RoHS ,REACH ,UL SGS to meet customer′s requirements.All workers are fully trained before going to production line.and Ensure 100% testing and inspecting before shipping .

Speed & Efficiency:

Concept to Design: < 3 business days

Goods lead time : 12-15 days

Rapid Prototyping: 4-7 days

Overseas Manufacturing

Utilized for larger production volumes and to ensure we can offer the most competitive pricing and Fast lead time to our customers
